    Hydraulic 50 - 60 Ton Dump Truck , HOWO 8x4 Strengthened Quad Axle Dump Truck

    Ask Lasest Price
    Brand Name : HOWO
    Model Number : ZZ3317N3567
    Certification : ISO9001
    Price : Negotiation
    Supply Ability : 30 UNITS PER MONTH
    Delivery Time : 30 Working Days
    • Product Details
    • Company Profile

    Hydraulic 50 - 60 Ton Dump Truck , HOWO 8x4 Strengthened Quad Axle Dump Truck

    50 - 60 tons SINOTRUK Dump Truck 4 axles HOWO 8x4 strengthened tipper truck

    371hp 12 wheels CNHTC HOWO dump truck,8x4 dumper truck

    Product features:

    1, Oil Saving, Safety, Driving comfort, Reliability, Low application cost
    2, Engine, Sinotruk WD615.47, 371HP or 290HP/36HP, German Man technology.
    3, Front dumper. dumper body: Square shape or U-shape.
    4, dumper body: 20cbm to 30cbm, heavy duty load capacity: 50ton to 60 ton
    Floor thickness: 8mm to 14mm, Side wall whickness: 6mm to 12mm for customers' different use
    5, Hydraulic system: HYVA brand or Chinese famous brand.

    Cabin

    HOWO 76 Standard Cab
    With two bunks, 70° hydraulically tillable to the front as attached photo for ref.

    Vehicle Main Dimensions(L x W x H)mm11645x2500x3400
    Wheel base (mm)1800+3500+1350
    Wheel track (front/rear) (mm)2022/1830
    Approach/Departure angle(°)19/18
    Weight in KGSTare Weight15680
    Loading Capacity16010
    Front axles loading capacity2x9000
    Rear axles loading capacity2x16000
    Max. driving speed(km/h)75
    EngineBrandSinotruk
    ModelWD615.47
    Type4-stroke direct injection , 6-cylinder in-line with water cooling, turbo-charging and inter-cooling
    Horse Power(HP)371HP
    Emission standardEuro
    GearboxHW19712 , 12 forwards & 2 reverse
    ClutchReinforced diaphragm clutch, diameter 430mm
    Steering GearZF 8118,power steering, hydraulic steering with power assistance
    Fuel tank (L)400
    Tire12R22.5 All steel radial tire is available , 12 pieces
    Brakes

    Service brake: dual circuit compressed air brake
    Parking brake :(emergency brake): spring energy, compressed air operating on rear wheels
    Auxiliary brake: engine exhaust valve brake



    dump Body


    Thickness

    Side6mm-12mm in high tensile strength steel Q345/B
    Front6mm-12mm in high tensile strength steel Q345/B
    Bottom8mm-14mm in high tensile strength steel Q345/B
    Dump body Size(L x W x H)7300mm x 2300mm x 1500mm


    Tipping hydraulics

    Tipping typeFront tipping type
    Tipping systemComplete set of HYVA brand hydraulics system
