SINOTRUK HOWO 8x4 Bulk Cement Truck For Transport Dry Bulk Powder
Material
Product features:
1, China Cement mixer truck,Famous HOWO chassis, 30cbm, 40cbm
2, Chinese famous brand or Imported hydraulic system /
Reducer/Motor
3, Well stirring, high speed of feeding & discharging;
4, Low oil consumption with good economic.
5, Factory directly sales
| Product | Bulk Cement Truck/ cement bulk truck for sale |
| Volume | Effective 38-40cbm/38000litres/10000gallons |
| Tanker material | High quality carbon steel 6mm |
Chassis | Brand | SINOTRUCK HOWO |
| Chassis model | ZZ1317N4667C |
| Drive type | 8×4, LHD/RHD |
| Tire | 12.00-20 |
| Tire No. | 12+1(spare) |
| Braking System | Air braking |
| Clutch | Uniwafer, dry clutch, hydraulic remote control |
| Transmission | 10 forward gear,1 reverse gear,manual mechanical type |
| Engine | Model | WD615.95E |
| Horse Power(hp) | 336 |
| Displacement(cc)/Power(kw) | 9726/247 |
| Emission | Euro 3 |
Main Parameters | Overall dimension (L*W*H/mm) | 11990*2500*3950mm |
| Wheelbase(mm) | 1800+4600+1350 |
| Axles No. | 4 |
| GVW(kg) | 31000 |
| Curb Weight(kg) | 16370 |
| Leaf spring No. | 11/11/12 |
| Approaching/Departure Angle(°) | 16/12 |
| Front/Rear trace(mm) | 2022/2022,2041/2041 |
| Front/Rear suspension(mm) | 1500/2740 |
| Max speed(km/h) | 90 |
| Front/Rear Axle Load(kg) | 6500/7000/17500 |
1. This Vehicle is specially used for bulk powder such as cement
,coal powder rash, lime powder and mineral powder which diameter
not more than 0.1mm transportation.
2. This vehicle is widely used in industry,agriculture ,commerce
and construction industry. The height of powder discharge could
be15m, horizontal distance is 5m.
3. The tank of this vehicle adopt of full automatic welding
technology, Y-type inside, with gravity point lower and large
capcity features.
4. Tanker material adopt of high quality carbon steel 5mm-6mm, Wuhu
air compressor or qingdao air compressor optional.
