    40m3 Powder Cement Tanker Trailer , 6 / 12 Tyre Heavy Duty Cement Bulker Trailer

    Ask Lasest Price
    Brand Name : SINOHTC
    Model Number : HTC9401FLWL
    Certification : ISO9001
    Price : Negotiation
    Supply Ability : 30 UNITS PER MONTH
    Delivery Time : 30 Working Days
    • Product Details
    • Company Profile

    40m3 Powder Cement Tanker Trailer , 6 / 12 Tyre Heavy Duty Cement Bulker Trailer

    40m3 Tanker bulk cement tank trailer truck for powder transport


    Functions :

    1. This series tank semi trailers are mainly used in heavy duty transportation for construction or logistic companies, such as fuel oil or liquid transporting
    2. The volume varies widely from 35 cubic meters to 60 cubic meters, we can manufacture it according to your needs.
    3. The axles can be Fuwa / Bpw with different tonnages by your need with price differences.
    4. The suspensions can be: Air suspension, mechanic (leaf spring suspension), bogie suspension, etc
    5. The loading deck can be concave beams, tire appeared cover, totally flatbed, or extendable.
    6. The loading ramps can be rear end designed, or front loading ladders, which can be mechanic spring ladders and hydraulic loading ramps by different needs .


    Tank Body
    ShapeOptional ( One Silo with V type or Two ,Three Silos Design)
    Dimension12000mm*2490mm*3990mm ( Exact size depends on the final design)
    Tare weightAbout 7500KGS-15000KGS
    Total Volume(m3)25m³-68 m³
    Tanker Body Material5mm or 6mm/ Q235 carbon steel
    End Plate5mm or 6mm /Q235 carbon steel
    Diesel EngineChina's brand
    CompressorBOHAI 10m³/12 m³or other brand
    Manhole CoverCarbon steel or Aluminum 500mm
    Discharging ValveDiameter is 3 or 4 inch (Material: Aluminum )
    Discharging Pipe3 or 4 inch rubber hose, 1pcs, 6m/each
    Cat WalkWith (Common model or special design)
    Chassis
    Main BeamsWelding Design ,Q345 carbon steel
    Axle2 or 3 axles, 12T/13T/16T, BPW/FUWA/HUAJING brand
    Landing GearJOST (D200T)or CHINA BRAND 28T
    King PinJOST 2.00 or 3.5 inch bolt-in king pin
    SuspensionMechanical suspension/Germany or America type /Air Suspension
    Leaf Spring90(W)mm*13(Thickness)mm*10 Layer or 100mm*12mm*12
    Pneumatic Braking SystemWABCO RE 6 relay valve; T30/30+T30 Spring brake chamber(TKL brand); 45L air tanks.
    Rim9.00-22.5/8.00-20/8.5-20 China Brand
    Tire12.00R22.5/315 80R22.5/11.00R20 /12.00R20 Brand can be Optional
    ABSOptional
    PaintingComplete Chassis sand blasting to clean rust, 1 coat of anticorrosive prime, 2 coats of final paint
    AccessoriesOne standard tool box
    Shipping TermsBy Bulk Cargo ,RORO
