3 axle GVW 60 Tons 6x4 Heavy Duty Truck Strengthened Mining Dump Truck

Quick Details for the GVW 60 Tons 6x4 Heavy Duty Truck Strengthened Mining Dump Truck

Drive Wheel: 6x4 Capacity (Load): 51 - 60t

Horsepower:336 - 371hp Condition: New

Transmission Type: Manual Emission Standard: Euro 2

Fuel Type: Diesel Engine Capacity: 9.726 L

Place of Origin: Shandong,China Brand Name: SINOTRUK HOVA

Model	mining dump truck
Engine	Type: Diesel 4-stoke Direct injection,6-cylinder in line, Turbo-charging, Inner cooling.
Model:	336HP/247KW	STEYR technology(CNHTC)
	Displacement(L):	9.726liter (Euro II standard)
	Max torque:	1350NM@1100-1600rpm
	Bore/stoke:	126mm/130mm
	Fuel consumption:	<193g /kwh
Gear box	CNHTC	Max torque:1900NM
	Model:	HW19710
	Speed:	10speed,2 reverse
Axle(front/rear)
Front axle	HW technology front steering axle
Tandem	AC16 STEYR technology double reduction hub reductor driving axle
Clutch	D430 diaphragm type clutch
Brake	Service brake: Dual lines air brake
	Parking brake: Spring-Power drum brake
	Engine brake: Engine exhaust brake(EVB)
Steering	ZF8118, driver sit at the left hand side
Electric Equipment
	Operating voltage:	24Vnegative grounded
	Starter:	24V,5.4KW
	Alternator	28V,758W
	Battery voltage	12V/135Ah,cigar lighter
Frame	Strengthen steel frame, designed according to tough road condition.
Tyre	10+1 spare tyre with rim
	13.00-24
Suspension system: Strongthen heavy duty Leaf spring type
Dump body:
Inside size of Body(mm): 5100x2800x1500 ,12x8mm, made of high intensity steel
Lifting type:Front lifter type HYVA hydraulic system
Overall dimension(mm): 7760x3000x3425(Length x Width x Height)
Wheelbase	3400+1400mm
Track:
	Approach/Departure angle	25/32.5
	Front /Rear overhang	1500/1560
	Max speed	69km/h
Kerb weight:	18415kg
Oil tank capacity	400L fuel tank

Qingdao Hetanch Truck Co., Ltd. is one of member of FAW Group before 2012. We are a group corporation that combines industry and trading. We supply products(axles, hydraulic cylinders and dump body) to FAW QINGDAO, SINOTRUK, SHACMAN, BEIBEN, FOTON, C&C and DAYUN. And at the same time we are the franchised dealer of FAW, CIMC, BEIBEN, SINOTRUK, SHACMAN, C&C, DAYUN series trucks. We can group buying from these manufacturer, so we can get more favorable price. Our products involve towing truck, semi-trailers, dump truck, concrete mixer truck and all kinds of special truck. As the distributor of them, we aim to bring the most reliable trucks to our customers worldwide. We also have set many branch offices in East-Asia, Middle-Asia, Africa and South-America.

With a team of professionals and the spirit of unceasingly innovation, we will always maintain the best attitude towards our respectable customers, because we adhere to our belief on the "high quality" principle.

We are customer focused and provide a superior quality service, take perfect service network, enthusiasm service attitude and strict service as norm from pre-sales to after-sales. We have our own office building and high character management team; We guarantee provide more perfect and satisfaction after-sales service for the customer. We sincerely invite friends and customers to visit our company to seek mutual development. Cooperate with us; You can get harmonious service like family.
