    50m3 4 Alxe Fuel Tanker Semi Trailer , Diesel / Petrol Trailer Tank 6 Compartments

    Ask Lasest Price
    Brand Name : SINOHTC
    Model Number : HTC9404GYYTG
    Certification : ISO9001
    Price : Negotiation
    Payment Terms : Western Union, L/C, T/T, MoneyGram
    Supply Ability : 50 UNITS PER MONTH
    Delivery Time : 30 DAYS
    • Product Details
    • Company Profile

    50m3 4 Alxe Fuel Tanker Semi Trailer , Diesel / Petrol Trailer Tank 6 Compartments

    50m3 4alxe fuel Tank semi trailer, four axle fuel Tanker trailer diesel,petrol,gasoline oil tanker trailer


    our fuel Tanker trailer, you can make 40 000 - 55 000 liters Oil tanker, 5 or more compartments,stainless or aluminum tanker material


    Specifications:


    Tank Body
    ShapeOptional (Round or Square)
    Dimension12500mm*2490mm*3990mm
    Tare WeightAbout 9600Kg
    Total Volume(m3)50.0 m3
    Tanker Body Material5mm or 6mm /Q235 carbon steel
    End Plate5mm or 6mm/Q235 carbon steel
    Manhole CoverCarbon steel or Aluminum alloy API manhole cover ,500mm
    Bottom VolumeAluminum API Pneumatic Bottom Valve
    Discharging ValveDiameter is 3 or 4 inch
    Compartments5 isolated compartments, Optional
    Discharging Pipe4" rubber hose,2 pcs,6m/each
    Cat WalkWith (Common model or special design)
    Chassis
    Main BeamsWelding design or special design I beam ,connected by bolts and nuts Q345 carbon steel material
    Axle4 axles, BPW/FUWA/JINSHENG brand
    Landing GearJOSTD200T or China brand 28T
    King PinJOST 2.00 OR 3.5 inch bolt-in king pin
    SuspensionMechanical suspension(Germany or American type)/air suspension
    Leaf spring90mm*130mm*10 or 100mm*12mm*12
    Pneumatic Braking SystemWABCO RE 6 relay valve; Spring brake chamber
    Rim9.00-22.5/8.00-20/8.5-20 China brand
    Tire12R22.5;315/ 80R22.5;11.00R20;12.00R20;
    No. of the Tire16
    ABSOptional
    PaintingComplete Chassis and blasting to clean rust,1 coat of anticorrosive prime,2 coats of final paint
    AccessoriesOne standard toolbox


    We are the full-size Modified Truck enterprise which integrate the design of product scientific research developing, production and sale together.


    Along with the development of Hetanch truck and trailer manufacture, we dedicate to improve the quality of our products and try our best to provide customers with good cost and performance products.


    In regards to manufacturing persisting the principle of "Best quality, Competitive price, Sincere Service."
