    200 Ton Multi Axle Modular Trailer , Hydraulic Steering Girder Bridge Trailer

    Ask Lasest Price
    Brand Name : SINOHTC
    Model Number : HTC9902DPB
    Certification : ISO9001
    Price : Negotiation
    Payment Terms : L/C, T/T, Western Union, MoneyGram
    Supply Ability : 10 UNITS PER MONTH
    Delivery Time : 60 DAYS
    • Product Details
    • Company Profile

    200 Ton Multi Axle Modular Trailer , Hydraulic Steering Girder Bridge Trailer

    300 ton Multi axle Modular Trailer,Hydraulic Steering modular trailer Girder Transporter


    this Multi axle Hydraulic Steering Modular Semi Trailer,is special desgin for big machine or equipment such as Girder,wind generater trannsportation on the road

    Details Specification:


    Hydraulic Gooseneck Modular Semi Trailer
    Tech Parameter- Per 2 Rows Line-Axle Modular
    Centerline Tare Weight3.5T
    Rated Capacity45T
    SuspensionStroke hydraulic + / - 300 mm
    Basic module width3.000 mm
    Angle of rotation axis±55°
    The control system
    Integrated into the central frame
    Air cylinders
    Oil tank
    Hydraulic systemSafety valves
    Main beam MaterialAH60,40Cr
    Main PartsCombinable heavy module 4 line-axlesCombinable heavy module 6 line-axles
    Outside Dimension6000mm*3000mm*1750+300mm9000mm*3000*+300mm
    Axles / Tires8 axles / 32 Tires12 axles / 48 Tires
    Total Dimension15000mm+3700mm+700mm *3000mm*1750+300mm
    Tire Size215/75 R 17,5
    Wheelbase1500mm
    Modules ConnectionsSide-battle for different combinations. Axle units mounted on the frame by bolting
    Equipment for Modular Combinations
    Diesel Power Plant22 KW
    Hydraulic Pump30 1/ min
    Standard Shaft3000mm long, flexible coupling ring, diameter 50 mm
    Operating head2 file combination
    Wireless Remote ControlHandheld operator panel / Transmitter - 1 piece
    Hydraulic bolted connector3 pcs
    Braking systemDual line braking system with automatic air brake and ABS
    Operating panel1 pc with leveling system
    Alarm panel2 pairs
    Flashing light2 pcs
    Tool Box1 set of standard tools
    Hydraulic Gooseneck
    Rated capacity35T
    Pin3.5-inch swivel pin
    Control systemIntegrated dual-control system
    ConnectorsHydraulic and pneumatic
    Taps3 - 4 pcs
    Other capacity with other dimensions optional

    This modular trailer,is the special vehicle which used for the heavy duty machine or equipment transport ,
    it can be assembled by customer request when you transport different machine or equipements
    12x2 24 line axles 200 ton for long machine transportation,
    24x4 or 13 x3 line 300ton for wide machine transportation.
    even can be made by your needs.

    BRIEF INTRODUCTION TO OUR trailer

    1.CCC&ISO Agreement, 1 Year Guarantee Term, Main-beam Lifetime Promise.
    2.Small Order Can Be Accepted.
    3.Any Color & Logo Available
    4.The Product Dimension + Specifications Can Be Designed As Your Needs
