    40 T 2 Axle Low Bed Semi Trailer High Strength Steel Material 8 Pcs Tyre

    Ask Lasest Price
    Brand Name : SINOHTC
    Model Number : HTC9402DPB
    Certification : ISO9001
    Price : Negotiation
    Payment Terms : L/C, T/T, Western Union, MoneyGram
    Supply Ability : 10 UNITS PER MONTH
    Delivery Time : 30 DAYS
    • Product Details
    • Company Profile

    40 T 2 Axle Low Bed Semi Trailer High Strength Steel Material 8 Pcs Tyre

    40 tons 2 axle Low bed trailer, dual axle heavy duty lowbed semi trailer, heavy duty lowbed trailer


    our 2 axle Low bed trailer, can be used to carry all kinds of middle duty earth moving machineries,

    Product Introduction
    The low bed trailer series products can be widely used to transport large goods, engineering equipments, large tanks and equipments of power station.
    The trailer is designed with the advanced software. It can be designed according to the requirements of customer, and to fulfill different kinds of transportation requirements.


    Technical Advantages
    1. It has the flat type, concave beam type and tyre appear type. The longitudinal beam uses the flat type or goose-neck type. The chassis is ladder type, longitudinal beam section is H-shaped. It has good rigidity and high strength.
    2. The main platform is lower, to realize a stable transportation. It is suitable for transporting different kinds of engineering equipments, large equipments and steel structures.
    3. This vehicle is using two or three axles balanced type, or rigid suspension, there is the balancer between the front and rear steel spring, and to match the same change of the front and rear spring comber and the same loading condition.

    Specifications:


    Trailer Model2 axle Low bed trailer,
    FunctionTractor and excavator transportation

    Overall Dimension

    (L*W *H)(mm)

    11800*2500*1700
    Tare Weight(KG)6500
    Loading Capacity(KG)40 000
    Axle BrandBPW/ 13ton
    Axle Number2
    Suspension SystemStandard Mechanical suspension
    Steel Spring10/10/10 leaf spring suspension
    Main Beam

    The height of the beam is 500 mm,the

    thickness of upper plate is16mm,down plate

    is 18mm,middle plate is 10mm.

    Floor4mm

    Tire Type

    and Quantity

    .8.25R17 8units
    Traction Pin50# or 90#, removeable
    Spare Wheel Bracket2 pieces
    Tool Box1 Standard
    Landing GearStandard 28Ton, external
    BrakingSystemDual Line braking system (none ABS)
    Brake air chamberSix big double air chamber
    Electrical System

    1. Voltage: 24v

    2. Receptacle: 7 ways (7 wire harness)

    Tail lamp with turn signal, brake light & reflector, side lamp etc.
    One set 6-core standard Cable.
    Side GuardAccording to customer's requirement
    PaintingOptional(yellow,red,white,blue etc.)
    PackingPolish with wax before shipping
